AE5400 er en nyre kondensatormikrofon med åpen, naturlig lydkvalitet og den tilfredsstiller den mest kritiske bruker. Den har element av stormembran og en "ekte-kondensator" konstruksjon.
- Element: Externally polarized (DC Bias) condenser
- Polar Pattern: Cardioid
- Frequency Response: 20-20,000 Hz
- Low-Frequency Roll Off: 80 Hz, 12 dB/octave
- Open Circuit Sensitivity: -40 dB (10.0 mV) re 1V at 1 Pa
- Impedance: 150 ohms
- Maximum Input Sound Level: 147 dB SPL, 1 kHz at 1% T.H.D.; 157 dB SPL, with 10 dB pad (nominal)
- Dynamic Range: 133 dB, 1 kHz at Max SPL
- Signal to Noise Ratio: 80 dB, 1 kHz at 1 Pa
- Phantom Power Requirements: 11-52V DC, 4 mA typical
- Weight: 11.6 oz (330 g)
- Dimensions: 7.05" (179.0 mm) long, 1.97" (50.0 mm) head diameter, 1.30" to 0.87" (33.0 mm to 22.0 mm) tapered body diameter
- Output Connector: Integral 3-pin XLRM-type
- Accessories: AT8470 Quiet-Flex® stand clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch
