General Specifications
Faders: 40 x 100mm touch-sensitive, motorised + 12 x 60mm touch sensitive, motorised
Screens: 3 x 21.3” LCD high-brightness, high-resolution touch screens + 3 x 6.8? LCD high-brightness, high-resolution touch screens
TFT Screens: 40 x 1.3? touch sensitive full colour LCD display + 29 x 1.3? full colour LCD displays
Meterbridge: 3 x Custom Mounted 19.2? LCD high – brightness, high – resolution screens
Redundancy: Internal removable engine x 2
Internal hot-swappable PSU x 2
Input Channels: 384
Busses Up: 192 Aux / Group busses with full processing Mono / Stereo / LCR / 5.1
Matrix: 64 Input / 64 Outputs with full processing
Control Groups: 36, selectable for VCA-style, Moving fader, Mute Group
Graphic Eq: 48 x 32-band, Gain +/- 12dB
Internal FX: 64 stereo effects comprising up to 32 floating point reverbs plus delay/chorus/pitch/enhancer
Spice Rack: 32 mono / 16 stereo Rack Slots
Mustard Proc: 128 Processing Strips
Nodal Proc: 384 Nodal Processors
Local I/O 12 x mic/line I/O, 12 x AES I/O
8 x MADI interfaces @ 48kHz, 4 redundant interfaces @ 96kHz, BNC connectivity
Standard Optocore (Dual Loop – Optional)
Sampling rates 48kHz / 96kHz
GPIO: 2 x DSub37
Video Inputs x 2, Outputs x 2
DMI: 2 x DiGiCo Multichannel Interface
Waves: Fitted as Standard
Ext Sync Wordclock, AES, Video, MADI, Optocore
